LDZA - LWOH

Cruise altitude between FL200 and FL330
LDZA (0.0nm) -SID-> TEBLI (41.4nm) -UL187-> KOMAR (56.9nm) -UL187->
EVTON (73.2nm) -UL187-> IDASI (88.9nm) -UM867-> SOLGU (120.9nm) -UM867->
GILUK (145.2nm) -UN132-> NILKU (185.7nm) -UN132-> NEPSI (190.0nm) -UN132->
AKIKA (248.7nm) -UN132-> MAVAR (315.0nm) -STAR-> LWOH (345.9nm)

Details:

---

ID      FREQ   TRK   DIST   Coords                       Name/Remarks
LDZA             0      0   N45°44'34.55" E016°04'07.60" ZAGREB / PLESO
TEBLI          145     41   N45°12'05.00" E016°40'33.00" TEBLI
KOMAR          163     16   N44°57'29.00" E016°48'15.00" KOMAR
EVTON          159     16   N44°42'35.00" E016°57'29.00" EVTON
IDASI          159     16   N44°28'13.00" E017°06'19.00" IDASI
SOLGU          135     32   N44°06'57.00" E017°39'41.00" SOLGU
GILUK          131     24   N43°52'01.00" E018°06'20.00" GILUK
NILKU          144     40   N43°20'55.00" E018°41'55.00" NILKU
NEPSI          144      4   N43°17'35.00" E018°45'40.00" NEPSI
AKIKA          144     59   N42°32'03.00" E019°36'14.00" AKIKA
MAVAR          145     66   N41°40'12.00" E020°31'48.00" MAVAR
LWOH           166     31   N41°10'47.72" E020°44'32.38" ST PAUL THE APOSTLE-OHRID

Tracks are magnetic, distances are in nautical miles.

---

LDZA SID TEBLI UL187 IDASI UM867 GILUK UN132 MAVAR STAR LWOH

LJLJ - LIPY

LIBD - LDRI

Computed route from BARI/PALESE (LIBD, LI) to RIJEKA / KRK I (LDRI, LD): 9 fixes, 292.4 nautical miles

Cruise altitude between FL200 and FL330
LIBD (0.0nm) -SID-> BANAV (37.1nm) -P748-> AIOSA (53.2nm) -UL862->
UVODI (130.7nm) -UL862-> SPL (156.1nm) -UL862-> PALEZ (228.9nm) -UL862->
GISER (261.9nm) -UL868-> KULEN (268.3nm) -STAR-> LDRI (292.4nm)

Details:

---

ID      FREQ   TRK   DIST   Coords                       Name/Remarks
LIBD             0      0   N41°08'17.49" E016°45'53.85" BARI/PALESE
BANAV           20     37   N41°43'42.56" E017°00'39.77" BANAV
AIOSA           45     16   N41°55'42.00" E017°14'54.00" AIOSA
UVODI          340     78   N43°06'39.00" E016°32'31.00" UVODI
SPL     115.7  339     25   N43°29'47.69" E016°18'17.00" SPLIT
PALEZ          336     73   N44°34'30.00" E015°31'59.00" PALEZ
GISER          335     33   N45°03'42.00" E015°10'26.00" GISER
KULEN          348      6   N45°09'55.00" E015°08'01.00" KULEN
LDRI           281     24   N45°13'00.80" E014°34'12.96" RIJEKA / KRK I

Tracks are magnetic, distances are in nautical miles.

---

LIBD SID BANAV P748 AIOSA UL862 GISER UL868 KULEN STAR LDRI

CHARTS EUROPE

http://www.uvairlines.com/admin/resources/charts/charts-europe.htm

LJLJ - LIPY

LIML - LJLJ

http://uvairlines.com/admin/resources/charts/LIML.pdf

LDZA - LIML

http://uvairlines.com/admin/resources/charts/LIML.pdf

LIRN - LGTS

Cruise altitude between FL200 and FL330
LIRN (0.0nm) -SID-> GALTI (31.3nm) -M742-> LUNAR (55.1nm) -M742->
BUMOK (66.7nm) -M742-> LUXIL (121.7nm) -L995-> ROBOT (149.7nm) -L995->
BRD (174.7nm) -M603-> XAPAT (187.8nm) -M603-> GOKEL (220.1nm) -UM603->
OVVER (266.4nm) -UM603-> ADDER (279.8nm) -UM603-> PINDO (309.6nm) -UM603->
KAS (324.3nm) -UM603-> EDASI (377.0nm) -STAR-> LGTS (402.1nm)

Details:

---

ID      FREQ   TRK   DIST   Coords                       Name/Remarks
LIRN             0      0   N40°53'04.08" E014°17'27.47" NAPOLI/CAPODICHINO
GALTI          120     31   N40°38'24.45" E014°53'56.74" GALTI
LUNAR           85     24   N40°41'25.84" E015°25'02.23" LUNAR
BUMOK           86     12   N40°42'51.06" E015°40'10.78" BUMOK
LUXIL           86     55   N40°49'08.64" E016°52'14.64" LUXIL
ROBOT          106     28   N40°42'35.00" E017°28'10.00" ROBOT
BRD     113.2  107     25   N40°36'39.10" E018°00'10.30" BRINDISI
XAPAT           94     13   N40°36'29.32" E018°17'25.92" XAPAT
GOKEL           94     32   N40°35'54.18" E019°00'00.00" GOKEL
OVVER           97     46   N40°32'30.00" E020°00'46.00" OVVER
ADDER           98     13   N40°31'26.00" E020°18'17.00" ADDER
PINDO           98     30   N40°28'51.00" E020°57'21.00" PINDO
KAS     114.5  100     15   N40°27'03.68" E021°16'31.15" KASTORIA
EDASI           93     53   N40°27'27.00" E022°25'39.00" EDASI
LGTS            85     25   N40°31'11.00" E022°58'15.30" THESSALONIKI/ MAKEDONIA

Tracks are magnetic, distances are in nautical miles.

---

LIRN SID GALTI M742 LUXIL L995 BRD M603 GOKEL UM603 EDASI STAR LGTS

http://www.uvairlines.com/admin/resources/charts/LIRN.pdf

http://www.aeolus.gr/pdfs/LGTS_JEP.pdf

LFPO Paris Orly Airport

http://www.pht-formation.fr/ops/SID%20STAR/LFPO%20-%20Paris%20Orly.pdf

DC 9-50 PODATKI

Poraba goriva: za 300 NM porabil 3179 lib. Let na višini FL310. Težko doseže višino.

https://en.wikipedia.org/wiki/McDonnell_Douglas_DC-9

LQBK - LATI

Computed route from BANJA LUKA INTERNATIONAL AIRP (LQBK, LQ) to TIRANA (LATI, LA): 15 fixes, 300.0 nautical miles

Cruise altitude between FL200 and FL330
LQBK (0.0nm) -SID-> KOMAR (21.0nm) -UL187-> EVTON (37.3nm) -UL187->
IDASI (53.0nm) -UM867-> SOLGU (85.0nm) -UM867-> GILUK (109.3nm) -UM867->
OSLUD (147.0nm) -UM867-> GORAV (163.3nm) -UM867-> BUNEX (175.1nm) -UM867->
MODRA (192.0nm) -UN732-> MOJ (195.8nm) -UN732-> POD (232.2nm) -UN732->
LEBGA (262.6nm) -UL607-> PETAK (271.7nm) -STAR-> LATI (300.0nm)

Details:

---

ID      FREQ   TRK   DIST   Coords                       Name/Remarks
LQBK             0      0   N44°56'29.03" E017°17'50.91" BANJA LUKA INTERNATIONAL AIRP
KOMAR          276     21   N44°57'29.00" E016°48'15.00" KOMAR
EVTON          159     16   N44°42'35.00" E016°57'29.00" EVTON
IDASI          159     16   N44°28'13.00" E017°06'19.00" IDASI
SOLGU          135     32   N44°06'57.00" E017°39'41.00" SOLGU
GILUK          131     24   N43°52'01.00" E018°06'20.00" GILUK
OSLUD          132     38   N43°28'38.00" E018°47'14.00" OSLUD
GORAV          132     16   N43°18'29.00" E019°04'40.00" GORAV
BUNEX          132     12   N43°11'03.80" E019°17'19.40" BUNEX
MODRA          133     17   N43°00'25.10" E019°35'19.50" MODRA
MOJ     308    192      4   N42°56'40.70" E019°34'31.90" MOJKOVAC
POD     113    207     36   N42°23'10.30" E019°15'16.60" PODGORICA
LEBGA          191     30   N41°52'59.30" E019°10'18.20" LEBGA
PETAK          139      9   N41°46'31.00" E019°18'50.00" PETAK
LATI           143     28   N41°24'53.00" E019°43'14.00" TIRANA

Tracks are magnetic, distances are in nautical miles.

---

LQBK SID KOMAR UL187 IDASI UM867 MODRA UN732 LEBGA UL607 PETAK STAR LATI

LDPL - PULA AIRPORT

LDPL Instrument Approach Chart - ICAO - NDBz RWY 27 Cat A_B
LDPL Standard Arrival Chart - Instrument (STAR) - ICAO - RWY 09_27
LDPL Instrument Approach Chart - ICAO - NDBy RWY 27
LDPL Instrument Approach Chart - ICAO - L RWY 09
LDPL Instrument Approach Chart - ICAO - VOR RWY 27
LDPL Instrument Approach Chart - ICAO - ILS or LOC RWY 27
LDPL Standard Departure Chart - Instrument (SID) - ICAO - RWY 09
LDPL Instrument Approach Chart - ICAO - VOR RWY 09
LDPL ATC Surveillance Minimum Altitude Chart - ICAO
LDPL Standard Departure Chart - Instrument (SID) - ICAO - RWY 27
LDPL Visual Operation Chart
LDPL Aerodrome Chart - ICAO
LDPL Aircraft Parking_Docking Chart - ICAO
LDPL Aerodrome Obstacle Chart - Type A - ICAO - RWY 09_27
LDPL Bird concentrations
AIP-LD LDPL AIP

LYTV - LDPL

Computed route from TIVAT (LYTV, LY) to PULA (LDPL, LD): 9 fixes, 304.7 nautical miles

Cruise altitude between FL200 and FL330
LYTV (0.0nm) -SID-> KOFER (28.8nm) -UL611-> VAKSU (36.8nm) -UL611->
AMUGO (89.4nm) -UL611-> UVODI (146.5nm) -UL862-> SPL (171.9nm) -UN606->
ZDA (226.3nm) -UN606-> PUL (304.5nm) -STAR-> LDPL (304.7nm)

Details:

---

ID      FREQ   TRK   DIST   Coords                       Name/Remarks
LYTV             0      0   N42°24'16.79" E018°43'23.83" TIVAT
KOFER          189     29   N41°55'38.00" E018°39'49.00" KOFER
VAKSU          314      8   N42°00'51.00" E018°31'37.00" VAKSU
AMUGO          311     53   N42°32'39.00" E017°35'02.00" AMUGO
UVODI          310     57   N43°06'39.00" E016°32'31.00" UVODI
SPL     115.7  339     25   N43°29'47.69" E016°18'17.00" SPLIT
ZDA     108.6  315     54   N44°05'43.16" E015°21'51.22" ZADAR
PUL     111.25 311     78   N44°53'32.52" E013°55'05.23" PULA
LDPL            71      0   N44°53'36.72" E013°55'19.89" PULA

Tracks are magnetic, distances are in nautical miles.

---

LYTV SID KOFER UL611 UVODI UL862 SPL UN606 PUL STAR LDPL

LBBG BURGAS

LBBG IAC VOR RWY 22(ICAO)
LBBG IAC RNAV(GNSS) RWY 22 (ICAO)
LBBG SID RNAV RWY 22 WEST ARNOV1V, BUVAK 1V, GONGO 1V, IXUKO 1V, TUGSO 1V (ICAO)
LBBG WAYPOINT LIST
LBBG VISUAL APPROACH CHART (ICAO) - BURGAS TRAFFIC PATTERN
LBBG STAR RNAV RWY 22 TRANSITIONS TO FINAL ESENA 2F, IXUKO 2F, NESAR 2F, RUTAR 2F, UVUDA 2F, VABUR 2F (ICAO)
LBBG VISUAL APPROACH CHART (ICAO) - BURGAS VFR ROUTES
LBBG SID RNAV RWY 22 EAST MEDEM 1V, MEDEM 1T, XILTI 1V, XILTI 1T (ICAO)
LBBG RADAR MINIMUM ALTITUDE CHART
LBBG IAC ILS or LOC RWY 22 (ICAO)
LBBG IAC RNAV(GNSS) RWY 04 (ICAO)
LBBG STAR RNAV RWY 04 TRANSITIONS TO FINAL ESENA 2D, IXUKO 2D, NESAR 2D, RUTAR 2D, UVUDA 2D, VABUR 2D (ICAO)
LBBG SID RNAV RWY 04 ARNOV 1S, BUVAK 1S, GONGO 1S, IXUKO 1S, MEDEM 2S, TUGSO 1S, XILTI 2S (ICAO)
LBBG AERODROME CHART (ICAO)
LBBG IAC VOR RWY 04 (ICAO)
LBBG AERODROME OBSTACLE CHART - ICAO TYPE A (OPERATING LIMITATIONS)
LBBG AIRCRAFT PARKING_DOCKING CHART (ICAO)
LBBG AIRCRAFT PARKING_DOCKING CHART(ICAO)
LBBG AERODROME CHART(ICAO)
LBBG SID RWY 22 UNIFORM DEPARTURES ESENA 3U GONGO 3U BUVAK 2U SUNIB 3U NESAR 4U MEDEM 1U OSVOP 2U IXUKO 2U(ICAO)
LBBG SID RWY 22 ECHO DEPARTURES ESENA 1E GONGO 1E BUVAK 1E
LBBG IAC ILS or LOC RWY 22(ICAO)
LBBG SID RWY 04 ESENA 3A GONGO 3A BUVAK 2A SUNIB 3Y NESAR 4A MEDEM 4A MEDEM 1W OSVOP 2A IXUKO 2A(ICAO)
LBBG AERODROME OBSTACLE CHART
AIP-LB LBBG AIP

Top Departures

ENGM
LRCL
EFRO
LOWG
URRR

Top Arrivals

LYNI
URRR
EDFH
OJAM
LOWG

LYNI - LBBG

Computed route from NIS / KONSTANTIN VELIKI (LYNI, LY) to BURGAS (LBBG, LB): 6 fixes, 258.8 nautical miles

Cruise altitude between FL200 and FL330
LYNI (0.0nm) -SID-> NISVA (46.8nm) -L614-> BLO (95.1nm) -T228->
GAPVO (109.8nm) -T228-> IXUKO (225.7nm) -STAR-> LBBG (258.8nm)

Details:

---

ID      FREQ   TRK   DIST   Coords                       Name/Remarks
LYNI             0      0   N43°20'14.24" E021°51'13.40" NIS / KONSTANTIN VELIKI
NISVA          122     47   N42°58'22.00" E022°47'51.00" NISVA
BLO     117.5  116     48   N42°40'02.00" E023°48'50.00" BAILOVO
GAPVO           91     15   N42°40'54.00" E024°08'44.00" GAPVO
IXUKO           96    116   N42°36'15.00" E026°46'03.00" IXUKO
LBBG            98     33   N42°34'13.00" E027°30'55.00" BURGAS

Tracks are magnetic, distances are in nautical miles.

---

LYNI SID NISVA L614 BLO T228 IXUKO STAR LBBG

LRTR (Timisuara)

LRTR AOC - ICAO - TYPE A RWY 11_29
LRTR AERODROME CHART - ICAO
LRTR AIRCRAFT PARKING_DOCKING CHART - ICAO - APRON
LRTR IAC - ICAO - NDB RWY 11
LRTR IAC - ICAO - ILS RWY 29
LRTR IAC - ICAO - NDB_DME RWY 29
LRTR SID - ICAO - RWY 29
LRTR RNAV (DME_DME) STAR - ICAO - RWY 11
LRTR RADAR MINIMUM ALTITUDE CHART - ICAO
LRTR RNAV (DME_DME) STAR - ICAO - RWY 29
LRTR SID - ICAO - RWY 11
LRTR STAR - ICAO - RWY 11
LRTR STAR - ICAO - RWY 29
LRTR IAC - ICAO - ILS RWY 11 CAT A_B
LRTR PRECISION APPROACH TERRAIN CHART - ICAO - RWY 11
LRTR AIRCRAFT PARKING_DOCKING CHART - APRON WEST
LRTR PRECISION APPROACH TERRAIN CHART - ICAO - RWY 29
AIP-LR LRTR AIP

LDZA - LYNI

Computed route from ZAGREB / PLESO (LDZA, LD) to NIS / KONSTANTIN VELIKI (LYNI, LY): 9 fixes, 297.1 nautical miles

Cruise altitude between FL200 and FL330
LDZA (0.0nm) -SID-> ZAG (13.5nm) -UN131-> GUBOK (96.6nm) -UN131->
DER (102.4nm) -UN131-> SOMUN (156.1nm) -UN131-> DIMSI (159.6nm) -UN131->
VAL (192.9nm) -UN131-> SOSEK (249.8nm) -STAR-> LYNI (297.1nm)

Details:

---

ID      FREQ   TRK   DIST   Coords                       Name/Remarks
LDZA             0      0   N45°44'34.55" E016°04'07.60" ZAGREB / PLESO
ZAG     113.7   50     14   N45°53'44.01" E016°18'24.11" ZAGREB
GUBOK          131     83   N45°02'41.00" E017°51'42.00" GUBOK
DER     112.4  132      6   N44°59'02.86" E017°58'10.06" DERVENTA
SOMUN          119     54   N44°35'47.00" E019°06'18.00" SOMUN
DIMSI          118      4   N44°34'18.00" E019°10'48.00" DIMSI
VAL     116.6  120     33   N44°19'26.00" E019°52'28.90" VALJEVO
SOSEK          128     57   N43°46'49.80" E020°57'19.80" SOSEK
LYNI           128     47   N43°20'14.24" E021°51'13.40" NIS / KONSTANTIN VELIKI

Tracks are magnetic, distances are in nautical miles.

---

LDZA SID ZAG UN131 SOSEK STAR LYNI

LIBP - LDZA

LRTR - LIBP

Computed route from TIMISOARA / TRAIAN VUIA (LRTR, LR) to PESCARA (LIBP, LI): 16 fixes, 407.8 nautical miles

Cruise altitude between FL200 and FL330
LRTR (0.0nm) -SID-> MAVIT (34.2nm) -UN188-> DONIV (64.3nm) -UN164->
XENIT (93.9nm) -UY88-> VAL (134.2nm) -UZ924-> BATRU (157.6nm) -UY88->
VEBAR (166.1nm) -UZ924-> KEB (199.9nm) -UY88-> GILUK (215.3nm) -UZ924->
VRANA (240.8nm) -UZ924-> PEVON (265.4nm) -UZ924-> SOMIG (313.6nm) -UZ924->
VELUG (345.7nm) -Z924-> ARSOB (373.2nm) -Z924-> ETRIN (382.1nm) -STAR->
LIBP (407.8nm)

Details:

---

ID      FREQ   TRK   DIST   Coords                       Name/Remarks
LRTR             0      0   N45°48'35.40" E021°20'16.34" TIMISOARA / TRAIAN VUIA
MAVIT          186     34   N45°14'24.00" E021°18'30.00" MAVIT
DONIV          195     30   N44°44'55.90" E021°10'10.40" DONIV
XENIT          215     30   N44°19'36.70" E020°48'45.10" XENIT
VAL     116.6  274     40   N44°19'26.00" E019°52'28.90" VALJEVO
BATRU          253     23   N44°11'06.00" E019°21'54.00" BATRU
VEBAR          254      8   N44°08'12.00" E019°10'49.00" VEBAR
KEB     116.7  253     34   N43°56'01.91" E018°26'59.38" SARAJEVO
GILUK          258     15   N43°52'01.00" E018°06'20.00" GILUK
VRANA          258     26   N43°45'13.00" E017°32'16.00" VRANA
PEVON          245     25   N43°33'31.21" E017°02'23.74" PEVON
SOMIG          245     48   N43°10'13.59" E016°04'25.91" SOMIG
VELUG          244     32   N42°54'27.07" E015°26'15.19" VELUG
ARSOB          243     28   N42°40'45.22" E014°53'46.31" ARSOB
ETRIN          243      9   N42°36'21.37" E014°43'12.08" ETRIN
LIBP           250     26   N42°26'14.00" E014°11'14.00" PESCARA

Tracks are magnetic, distances are in nautical miles.

---

LRTR SID MAVIT UN188 DONIV UN164 XENIT UY88 VAL UZ924 BATRU UY88 VEBAR UZ924 KEB UY88 GILUK UZ924 VELUG Z924 ETRIN STAR LIBP

LWOH - LRTR

Computed route from ST PAUL THE APOSTLE-OHRID (LWOH, LW) to TIMISOARA / TRAIAN VUIA (LRTR, LR): 7 fixes, 304.7 nautical miles

Cruise altitude between FL200 and FL330
LWOH (0.0nm) -SID-> MAVAR (30.9nm) -UN146-> ALELU (88.2nm) -UM173->
ELGEB (189.1nm) -UP129-> IRGOR (232.1nm) -UP129-> MAVIT (270.4nm) -STAR->
LRTR (304.7nm)

Details:

---

ID      FREQ   TRK   DIST   Coords                       Name/Remarks
LWOH             0      0   N41°10'47.72" E020°44'32.38" ST PAUL THE APOSTLE-OHRID
MAVAR          346     31   N41°40'12.00" E020°31'48.00" MAVAR
ALELU          332     57   N42°28'45.00" E019°51'02.00" ALELU
ELGEB           12    101   N44°08'26.30" E020°11'32.50" ELGEB
IRGOR           39     43   N44°43'22.00" E020°46'35.80" IRGOR
MAVIT           40     38   N45°14'24.00" E021°18'30.00" MAVIT
LRTR             6     34   N45°48'35.40" E021°20'16.34" TIMISOARA / TRAIAN VUIA

Tracks are magnetic, distances are in nautical miles.

---

LWOH SID MAVAR UN146 ALELU UM173 ELGEB UP129 MAVIT STAR LRTR

LWOH SID RWY 01   LWOH SID RWY 19   LRTR STAR MAVIT RWY 11
